Custom LiPo 741473 3.7V 1400mAh Battery for Portable Electronics & RC Models

LiPo 3.7V 1400mAh Rechargeable Batteries wholesale

Product Model: LiPo Battery 741473 3.7V 1400mAh

High Discharge, Custom Solutions:

Himax LiPo batteries deliver superior high discharge rates, ideal for drones, RC vehicles, and more. We offer custom battery packs and bulk orders with competitive wholesale pricing and fast global shipping to meet your specific needs.

Product Description:

No Memory Effect

LiPo battery 3.7V 1400mAh can be recharged at any time without needing to fully discharge first, providing convenience and longevity.

High Energy Density

Provides a significant amount of energy relative to its size and weight.
.

Compact Form Factor

Can be designed in various shapes and sizes to fit different devices and applications.

Technical Parameters:

Part Number	LiPo battery 3.7V 1400mAh
MAIN PARAMETER
Rated Capacity	1400mAh
Nominal Voltage	3.7V
Max Charge Voltage	4.2V
Discharge Cut Off Voltage	3.0V
Charging Current	1400mA
Max. Continuous Discharging Current	5000mA
Cycle Life	300 times at 100% DOD
Discharge Rate	0.2C
MECHANICAL SPECIFICATIONS
Dimensions (TWH)	741515mm
Weight	Approx 25g
Encapsulation	Customized is avaliable
OTHERS
Operating Temperature	Charge : 0℃-45℃ Discharge : -20℃-60℃
Storage Temperature	-10°C~45°C
Humidity	65±20%
Certification	UN38.3/MSDS
Main protection function	Over charge,Over discharge, Over current, Short circuit etc.
Delivery period	Depend on the order quantity
Warranty	1 year from the date of shipping
APPLICATIONS
Portable Electronics，RC Models，Consumer Electronics， etc.

FAQ

Frequently Asked Questions (FAQs)

What devices is the 3.7V 1400mAh LiPo battery compatible with?

This battery is widely used in Bluetooth speakers, dash cams, GPS units, digital cameras, e-books, and other compact consumer electronics requiring reliable 3.7V power.

Does this LiPo battery include protection circuitry?

Yes. The integrated PCM provides over-charge, over-discharge, over-current, and short-circuit protection, ensuring safe operation across diverse applications.

What are the charging specifications for the 741473 LiPo cell?

Standard charge current is 0.2C (280mA), with a maximum of 1C (1400mA). The maximum charge voltage is 4.2V, and the discharge cut-off voltage is 3.0V.

Can Himax customize the 1400mAh LiPo battery for my specific requirements?

Absolutely. We offer custom dimensions, connector types, wire lengths, PCM parameters, and capacity adjustments to match your device specifications.

What is the typical cycle life of this 3.7V 1400mAh battery?

The battery delivers approximately 300–500 charge cycles at 100% depth of discharge, maintaining stable performance throughout its lifespan.

Download

Custom LiPo Battery

Customization Process & Requirements

Customization Process

Step 1 – Requirement Submission

Share your target specifications: capacity, voltage, dimensions (T×W×H), discharge rate, connector type, and application details.

Step 2 – Engineering Review

Our engineers evaluate feasibility and provide a technical proposal, including recommended cell model, PCM configuration, and wire harness design.

Step 3 – Sample Development

We produce prototype samples for your validation. Typical lead time is 7–15 working days, depending on complexity.

Step 4 – Testing & Approval

Samples undergo capacity, cycle life, safety, and environmental testing. You confirm performance before mass production.

Step 5 – Mass Production & Delivery

Upon sample approval, we begin production with strict QC at every stage. Global shipping options are available.

Customization Requirements

Minimum order quantity: negotiable based on project scale
Custom dimensions: available within cell manufacturing tolerances
Connector options: JST, Molex, custom wire harnesses
Certifications: REACH, RoHS, and other standards as required
Packaging: bulk, retail, or custom labeling

Kindly Reminders: • Production time: 10 to 15 days for samples; 25 to 30 days for bulk orders. • Transportation methods: By couriers, air, truck, sea. • Payment terms: TT/PayPal/Assurance order.
